With Two-Axis Computer Control and manually controlled bevel angles, the W-122 is a two axis pipe cutter complete with 24ft capacity roller bed capable of cutting diameters from 1” pipe (1.31” O.D.) to 12.750” O.D.
With Two-Axis Computer Control and manually controlled bevel angles. The W-242 is controlled by a heavy-duty industrial computer designed to run in extremes of temperature, humidity and vibration. The bevel angles are preset on the indicator gauge rather than computer controlled like the four axis W-242. Where thick pipe is used and the bevel gap must be precisely controlled for deep weld penetration the W-244 is preferred.
The W-244 is controlled by a heavy-duty industrial computer designed to run in extremes of temperature, humidity and vibration. All controls are remotely mounted at the cutting head for easy access. The W-244 uses the latest computer motion-control systems along with an innovative floating headstock and cutting head design. Only a floating headstock and cutting head allows smooth accurate handling of irregular pipe that could cause erratic cutting with a typical headstock.
The W-364 can cut 36 inch pipe with an optimum bevel angle throughout the cut. This is ideal for large pipe requiring pass through pipe connections or “hole in” fittings.
The Watts W-484 Four (4) Axis Pipe & Vessel Shell Cutting Machine will dramatically increase your pipe cutting and pipe beveling productivity. It will also increase your dimensional accuracies and make the fit up much easier with the oxy/fuel or the plasma arc cutting processes. The 3rd and 4th Axis of motion allows the torch to rotate along the linear axis of the pipe and perpendicular to the linear axis to perform true beveled holes and end cuts.
The W-60-20 is a preferred machine in schools and training facilities.
The W-60-20SM cuts straight cuts, miters, and 90 degree saddles on pipe up to 12”. Set the cam using the chart on the side of the machine to produce the shape desired.
The W-116 LPSC is a pipe cutter capable of cutting from 1 1/2” to 16” diameter pipe up to 20’ long. (Additional lengths are available).
The 132 LPSC is a pipe cutter capable of cutting from 3” to 32” diameter pipe up to 20’ long (optional lengths available).
The W-50 Weld Tester is a destructive weld testing machine that incorporates compression, tensile, and bend testing in one complete unit. The W-50 is an invaluable asset to any training facility or commercial company that requires welder qualification. The W-50 can do all the destructive tests as specified by AWS, ASME, and API.
Rotate your work at a controlled speed. The foot-pedal speed controller keeps both hands free for welding, or use the panel control. Chuck anything up to 12 inches in the internal jaws.
Tilt-Head Welding Positioner capable of holding and positioning cylindrical parts up to 350 lbs vertically or 250 lbs horizontally (calculated at 2 in. from the face plate). This heavy duty rotary positioner is precise, smooth and easily controlled. Rotation speed is adjusted with the control panel and an on/off switch is activated by the foot pedal.
